Material Handling Delivery Hose

Description

Our Material Handling Delivery Hose is engineered for reliability in oil and fuel applications.
Designed with superior materials, it offers excellent resistance to abrasion, weather, and ozone, ensuring long-lasting performance across industrial settings.

• Tube: High abrasion resistant conductive black NR.
• Reinforcement: High-tensile synthetic cord with antistatic copper wire.
• Cover: Weather, ozone resistant, abrasion resistant, cloth impression black EPDM.
• Temperature Range: -30°C to +70°C (-22°F to +158°F)
• Remarks: Upon request heavy version 17 bar (250 ppm) available, also suitable for offshore industry.
• Application: Used for delivery of dry powder, slurry and cement.

code	inch	mm	mm	bar	psi	bar	psi	gr/mt	mm	mt
MM-010-025-V	1	25	37	10	150	30	450	645	200	20-40
MM-010-032-V	1 1/4	32	44	10	150	30	450	850	255	20-40
MM-010-038-V	1 1/2	38	52	10	150	30	450	1200	300	20-40
MM-010-051-V	2	51	65	10	150	30	450	1480	410	20-40
MM-010-063-V	2 1/2	63	78	10	150	30	450	1950	510	20-40
MM-010-076-V	3	76	93	10	150	30	450	2650	600	20-40
MM-010-102-V	4	102	122	10	150	30	450	4420	800	20-40
MM-010-127-V	5	127	149	10	150	30	450	6300	1000	20-40
MM-010-152-V	6	152	174	10	150	30	450	7700	1200	20-40
