CONCRETE HOSE – STEEL – 85 BAR (1233 PSI)

Description

CONCRETE HOSE – STEEL – 85 BAR (1233 PSI)

Our CONCRETE/1 is engineered for long term strength abrasive, plaster, cement applications.
Designed with superior materials, it offers excellent resistance to abrasion, weather, and ozone, ensuring long-lasting performance across industrial settings.

• Tube: High abrasion resistant  black NR
• Reinforcement: High-tensile steel cords.
• Cover: Weather, ozone resistant, abrasion resistant, cloth impression black SBR/NBR
• Temperature Range: -30°C to +70°C (-22°F to +158°F)
• Remarks: Standart DIN 53516, below: 50 mm3

Application:

• Used for high pressure concrete pumping applications.

code	inch	mm	mm	bar	psi	bar	psi	gr/mt	mm	mt
MM-085-051-A	2	51	71	85	1233	200	2900	3100	275	40
MM-085-063-A	2 1/2	63	85	85	1233	200	2900	4500	300	40
MM-085-065-A		65	87	85	1233	200	2900	4750	325	40
MM-085-076-A	3	76	100	85	1233	200	2900	5500	350	40
MM-085-102-A	4	102	126	85	1233	200	2900	8500	400	40
MM-085-127-A	5	127	155	85	1233	200	2900	9700	500	40
MM-085-152-A	6	152	180	85	1233	200	2900	11200	700	40
