Marine Fuel Fill Suction and Delivery Hose

Description

Our Marine Fuel Fill Suction and Delivery Hose is engineered for reliability in oil and fuel applications.
Designed with superior materials, it offers excellent resistance to abrasion, weather, and ozone, ensuring long-lasting performance across industrial settings.

• Tube: Oil and fuel resistant conductive black NBR.
• Reinforcement: High-tensile synthetic cord with wire helix and antistatic copper wires.
• Cover: Oil, weather and ozone resistant, smooth cloth impression black CR.
• Temperature Range: -30°C to +70°C (-22°F to +158°F)
• Remarks: Standart ISO 7840-A2;SAE J 1527; upon request also available with corrugated cover.
• Application: Used for oil and fuel services in marine industry.

code	inch	mm	mm	bar	psi	bar	psi	gr/mt	mm	mt
ME-010-019-A	3/4	19	29	10	150	30	450	670	120	20-40
ME-010-025-A	1	25	35	10	150	30	450	830	150	20-40
ME-010-032-A	1 1/4	32	42	10	150	30	450	950	190	20-40
ME-010-038-A	1 1/2	38	50	10	150	30	450	1150	230	20-40
ME-010-051-A	2	51	63	10	150	30	450	1500	300	20-40
