Material Handling Suction and Delivery Hose

Description

Our Material Handling Suction and Delivery Hose is engineered for reliability in oil and fuel applications.
Designed with superior materials, it offers excellent resistance to abrasion, weather, and ozone, ensuring long-lasting performance across industrial settings.

• Tube: High abrasion resistant conductive black NR.
• Reinforcement: High-tensile synthetic cord with wire helix and antistatic copper wire.
• Cover: Weather, ozone resistant, abrasion resistant, cloth impression black EPDM.
• Temperature Range: -30°C to +70°C (-22°F to +158°F)
• Remarks: Upon request heavy version 17 bar (250 ppm) available, also suitable for offshore industry.
• Application: Used for suction and discharge of dry powder, slurry and cement.

code	inch	mm	mm	bar	psi	bar	psi	gr/mt	mm	mt
MM-010-025-A	1	25	39	10	150	30	450	900	150	20-40
MM-010-032-A	1 1/4	32	45	10	150	30	450	1075	190	20-40
MM-010-038-A	1 1/2	38	52	10	150	30	450	1500	230	20-40
MM-010-051-A	2	51	66	10	150	30	450	2000	300	20-40
MM-010-063-A	2 1/2	63	80	10	150	30	450	2980	380	20-40
MM-010-076-A	3	76	94	10	150	30	450	4050	460	20-40
MM-010-102-A	4	102	122	10	150	30	450	5200	600	20-40
MM-010-127-A	5	127	149	10	150	30	450	6900	750	20-40
MM-010-152-A	6	152	174	10	150	30	450	8800	900	20-40
