BUNKERING SUCTION AND DELIVERY HOSE 17 BAR (250 PSI)

Description

BUNKERING SUCTION AND DELIVERY HOSE 17 BAR (250 PSI)

Our Bunk/SD Hose is engineered for reliability in oil and fuel applications.
Designed with superior materials, it offers excellent resistance to abrasion, weather, and ozone, ensuring long-lasting performance across industrial settings.

• Tube: Oil & Fuel resistant conductive black NBR.
• Reinforcement: High-tensile synthetic cord with steel wire helix and double copper wires.
• Cover: Oil, weather and ozone resistant, smooth, cloth impression black Neoprene rubber .
• Temperature Range: -40°C to +95°C (-40°F to +203°F))

Applications:

• Ideal for use handling of high pressure discharge of petroleum products with aromatic content up to %50

code	inch	mm	mm	bar	psi	bar	psi	gr/mt	mm	mt
MO-017-051-AVBK	2	51	66	17	250	64	1000	2000	300	40
MO-017-076-AVBK	3	76	94	17	250	64	1000	3450	400	40
MO-017-102-AVBK	4	102	120	17	250	64	1000	5000	500	40
MO-017-127-AVBK	5	127	151	17	250	64	1000	7850	600	40
MO-017-152-AVBK	6	152	176	17	250	64	1000	9250	800	40
MO-017-203-AVBK	8	203	231	17	250	64	1000	16750	1200	20
