- Description
Description
OILFIELD HOSE 150 PSI
Our OILFLD Hose is engineered for reliability in oil and fuel applications.
Designed with superior materials, it offers excellent resistance to abrasion, weather, and ozone, ensuring long-lasting performance across industrial settings.
- Tube: Oil & Fuel resistant conductive black NBR.
- Reinforcement: High-tensile synthetic cord with wire helix antistatic copper wires.
- Cover: Oil, weather and ozone resistant, smooth, cloth impression black CR.
- Temperature Range: -30°C to +70°C (-22°F to +158°F)
- Remarks: Upon request also available with 4:1 safety factor for offshore industry.
 |  |  |  |  |  |  | ||||
| code | inch | mm | mm | bar | psi | bar | psi | gr/mt | mm | mt |
| MO-010-019-V | 3/4 | 19 | 30 | 10 | 150 | 30 | 450 | 550 | 160 | 20-40 |
| MO-010-025-V | 1 | 25 | 36 | 10 | 150 | 30 | 450 | 650 | 200 | 20-40 |
| MO-010-032-V | 1 1/4 | 32 | 43 | 10 | 150 | 30 | 450 | 830 | 255 | 20-40 |
| MO-010-038-V | 1 1/2 | 38 | 49 | 10 | 150 | 30 | 450 | 980 | 300 | 20-40 |
| MO-010-051-V | 2 | 51 | 63 | 10 | 150 | 30 | 450 | 1400 | 410 | 20-40 |
| MO-010-063-V | 2 1/2 | 63 | 76 | 10 | 150 | 30 | 450 | 1830 | 500 | 20-40 |
| MO-010-076-V | 3 | 76 | 90 | 10 | 150 | 30 | 450 | 2400 | 600 | 20-40 |
| MO-010-102-V | 4 | 102 | 118 | 10 | 150 | 30 | 450 | 3700 | 800 | 20-40 |
| MO-010-127-V | 5 | 127 | 143 | 10 | 150 | 30 | 450 | 4300 | 1000 | 20-40 |
| MO-010-152-V | 6 | 152 | 168 | 10 | 150 | 30 | 450 | 5000 | 1200 | 20-40 |
