Description
Our Radiator Hose is designed for handling hot water in the automotive industry with excellent performance and durability.
Built with high-quality materials, it ensures long-lasting reliability even under challenging conditions.
- Tube: Hot water resistant, smooth black EPDM.
- Reinforcement: High-tensile synthetic cord for enhanced strength.
- Cover: Smooth, cloth impression black EPDM for superior durability.
- Temperature Range: -30°C to +120°C (-22°F to +248°F)
Applications:
- Ideal for handling hot water in automotive radiators.
- Flexible corrugated version available upon request.
| Code | ID (inch) | ID (mm) | OD (mm) | WP (bar) | WP (psi) | BP (bar) | BP (psi) | Weight (gr/mt) | Bend Radius (mm) | Length (m) |
|---|---|---|---|---|---|---|---|---|---|---|
| MW-005-006-VYR | 1/4 | 6 | 13 | 5 | 75 | 15 | 225 | 120 | 65 | 1-40 |
| MW-005-008-VYR | 5/16 | 8 | 16 | 5 | 75 | 15 | 225 | 145 | 75 | 1-40 |
| MW-005-010-VYR | 3/8 | 10 | 19 | 5 | 75 | 15 | 225 | 180 | 90 | 1-40 |
| MW-005-013-VYR | 1/2 | 13 | 23 | 5 | 75 | 15 | 225 | 250 | 105 | 1-40 |
| MW-005-019-VYR | 3/4 | 19 | 29 | 5 | 75 | 15 | 225 | 390 | 120 | 1-40 |
| MW-005-025-VYR | 1 | 25 | 37 | 5 | 75 | 15 | 225 | 670 | 140 | 1-40 |
| MW-005-032-VYR | 1 1/4 | 32 | 45 | 5 | 75 | 15 | 225 | 950 | 170 | 1-40 |
| MW-005-038-VYR | 1 1/2 | 38 | 53 | 5 | 75 | 15 | 225 | 1300 | 190 | 1-40 |
| MW-005-051-VYR | 2 | 51 | 65 | 5 | 75 | 15 | 225 | 1800 | 230 | 1-40 |
| MW-005-063-VYR | 2 1/2 | 63 | 76 | 5 | 75 | 15 | 225 | 2105 | 300 | 1-40 |
| MW-005-076-VYR | 3 | 76 | 89 | 5 | 75 | 15 | 225 | 2600 | 380 | 1-40 |
| MW-005-102-VYR | 4 | 102 | 114 | 5 | 75 | 15 | 225 | 5400 | 540 | 1-40 |
