OIL FUEL & DELIVERY HOSE 20 BAR (300 PSI)

Description

OIL FUEL & DELIVERY HOSE 20 BAR (300 PSI)

Our Oil & Fuel Delivery Hose is engineered for reliability in oil and fuel applications.
Designed with superior materials, it offers excellent resistance to abrasion, weather, and ozone, ensuring long-lasting performance across industrial settings.

• Tube: Oil & Fuel resistant conductive black NBR.
• Reinforcement: High-tensile synthetic cord with antistatic copper wires.
• Cover: Oil, weather and ozone resistant, smooth, cloth impression black NBR.
• Temperature Range: -30°C to +70°C (-22°F to +158°F)
• Remarks: Upon request also available with 4:1 safety factor for offshore industry.

Applications:

• Ideal for use high pressure discharge of petroleum products with aromatic content up to %50

code	inch	mm	mm	bar	psi	bar	psi	gr/mt	mm	mt
MO-020-019-V	3/4	19	30	20	300	60	900	625	160	20-40
MO-020-025-V	1	25	36	20	300	60	900	680	200	20-40
MO-020-032-V	1 1/4	32	44	20	300	60	900	850	255	20-40
MO-020-038-V	1 1/2	38	51	20	300	60	900	1250	300	20-40
MO-020-051-V	2	51	66	20	300	60	900	1600	410	20-40
MO-020-063-V	2 1/2	63	78	20	300	60	900	2050	500	20-40
MO-020-076-V	3	76	92	20	300	60	900	2750	600	20-40
MO-020-102-V	4	102	119	20	300	60	900	3950	800	20-40
MO-020-127-V	5	127	146	20	300	60	900	4800	1000	20-40
MO-020-152-V	6	152	172	20	300	60	900	6000	1200	20-40
